Vision Optronix is a Systems Designer and Integrator for markets including; Industrial, Scientific, Aerospace, and Security. We are an authorized distributor of infrared cameras, objective lenses, and illuminators.

OPEN POSITIONS

industrial-1


Vision Optronix is an authorized distributor of cameras, lenses and custom illuminators.

Uncooled BroadBand Infrared Camera Core

With a broadband response over wavelengths from 2μm - 14μm, this Camera Core integrates a 640 x 480 (VGA) format amorphous silicon sensor with 17μm pixels. The Camera Core offers simultaneous NTSC and CameraLink outputs. A GigE interface is also available.

APPLICATIONS:

  • High Temperature (>200°C/400°F) Thermometry
  • Furnace, Boiler, Kiln Inspection
  • High Temperature Process Monitoring (e.g., Combustion)
  • Infrared Optical Metrology
  • Chemical and Biological (MIR) Imaging
  • Laser Spectroscopy
  • Laser Beam Profiling
  • Laser Materials Processing/Weld Process Monitoring
  • Machine Vision

REQUEST A DATA SHEET

By Visimid

High-Speed, Low-Noise Near Infrared/Shortwave Infrared Camera

With an infrared response over wavelengths from 900nm – 1700nm, this camera integrates a 640 x 512 format InGaAs Sensor with 15μm pixels and can operate at up to 400Hz frame rates. With a low dark current sensor and exceptionally low-noise readout, this camera can be used with exposure times from <1μs to seconds. The camera can be operated at ambient temperature or with a cooling loop for even lower dark currents/longer exposure times.

APPLICATIONS:

  • Adaptive Optics for Biology and Astronomy
  • OCT (Optical Coherence Tomography) Imaging
  • Biological (NIR) Imaging
  • Semiconductor Inspection and Microscopy
  • Spectroscopy and Hyperspectral Imaging
  • Laser Communications
  • Machine Vision

REQUEST A DATA SHEET

By FirstLight Imaging

Broadband Infrared Microscope Objective

Designed for use with our Broadband Infrared Camera Core, this high-resolution, broadband lens offers a numerical aperture of 0.85, a 20x magnification, and is compatible with image sensors with 1024 x 768, 17μm formats. It is color corrected from 2μm - 15μm and exhibits high transmission.

APPLICATIONS:

  • Chemical and Biological (MIR) Imaging
  • Imaging Spectroscopy

Design and Integration Services for Optical and Photonic Systems

Vision Optronix provides full design and integration services for machine vision, chemical and biological imaging, surveillance, and more.
